WEH® Fueling System TS55 CNG
For buses / trucks (ECE), 200 bar
Codice
C1-62854
0,00 €
A WEH® Fuelling system for refuelling buses and trucks is also available. The TS55 CNG consists of a fully assembled housing with an integrated large receptacle and enables easy retrofitting of buses and trucks to compressed natural gas. The converted vehicle can be easily refuelled from the outside by simply removing the fuel tank cap and connecting the nozzle to the receptacle. Then refuelling can start.
The integrated WEH® TN5 CNG receptacle ensures rapid filling with a high flow rate and reduced noise during refuelling.
The fuelling system consists of two preinstalled housings for mounting into the vehicle.
| Nominal bore (DN) | 12 mm |
|---|---|
| Pressure Range | PN = 200 bar | PS = 260 bar (ECE) |
| Temperature Range | -40 °C fino a +120 °C (ECE) |
| Design | Con valvola di carica TN5 CNG sin filtro, tappo e raccordi Opzione: Valvola di carica TN5 CNG con filtro |
| Material | Corpo |
| Sealing Material | Resistenti al gas metano |
| Approval | ECE R110 (si applica a TN5 CNG) |
- Ermetico contro lo sporco e gli spruzzi d’acqua
- Pratico tappo del serbatoio
- Valvola di carica integrata WEH® TN5 CNG senza filtro
- Nessun pericolo di formazione di ghiaccio
- Opzione: interruttore interruzione avvitamento
Fueling system for installation in buses and trucks. Only use fueling systems with ECE approval for fitment in road legal vehicles.
