WEH® Connector TW713
Using the WEH® TW723 fuel connector, confined spaces are no problem when checking fuel lines on engine test stands. The design of the quick connector, with its central media inlet (optionally available as a 90° version), makes your work processes much easier. Complicated testing devices are no longer needed.
Nor is it necessary to laboriously screw connecting parts in and out, not just saving you time and money, but also reducing strain on your employees’ joints. The pressure-tight connection is established in seconds without delaying production workflows.
The shut-off valve integrated into the part prevents fuel leaking out when it is not connected. This feature is good for climate protection and also ensures that your workspace is clean and safe.
| Max. allowable operating pressure PS | 10 bar (145 psi) |
|---|---|
| Pilot Pressure | 6 bar (90 psi) |
| Temperature Range | +5 °C up to +100 °C |
| Medium | Petrol, Diesel, compressed air |
| Media Inlet | G1/8" female thread |
| Actuation | Pneumatic actuation, automation is also possible |
| Design | With integrated shut-off valve |
| Material | Corrosion resistant |
| Sealing Material | FKM |
- Automation possible
- Central test port
- Connection in seconds
- High-grade materials
- Increased productivity & Cost reductions
- Integrated shut-off valve
- No hand tightening required
- Robust construction
